SPview 官方最新版v3.5.3

SPview官方版(s2p文件查看分析工具)是查看s2p文件的好工具，查看s参数，smith圆图，支持脚本操作等功能。软件功能非常强大，界面简洁明晰、操作方便快捷，设计得很人性化。SPview官方版支持Windows XP/Vista/Win7/8/10系统，能来查看SPV/ALB/S1P/MDF/LP/SP/LPD格式文件。需要的朋友千万不要错过哦！

SPview官方版英文简介

　　SPview is an S-Parameter toolset for RF and Microwave engineering.With built in GPIB, LAN, USB and RS232 capabilities, it can capture data directly from Vector Network Analyzers, Spectrum Analyzers, Scalar Analyzers and Oscilloscopes. It can produce S-parameter files compatible with all major simulators. Built in charting and data manipulation features enable faster circuit design, the2-port functions charts are particularly useful for amplifier designers often removing several measure/simulate cycles.

　　SPview gives older VNA's the facilities available in newer and more expensive models and additionally it can capture N-port data, that is, 3,4..99 port data can be captured using only a 2-port or T/R Analyser and saved as S-parameter files.

　　Spview supports National Instruments NI488, Agilent SICL libraries along with VISA from many vendors. RS USB smart instruments are also supported.

　　No third party drivers/libraries are require to capture data from instruments equipped with a LAN port.

　　SPview can also import and Contour map Load-pull data from both Focus and Maury file formats.

　　The optional toolset SI pack enables a range of Signal Integrity functions and transforms including the Mixed-mode differential and common mode transform and eye diagram plotter.

　　SPview 3 now includes a full multiport linear simulator complete with visual schematic editor. Data files can be drag and dropped onto schematics and connected to other components such as resistors, capacitors, inductors and transmission lines. Ports can be changed to any arbitrary real impedance and the schematic editor also includes a NEG2 element to allow S-parameter data to be de-embedded on a port by port basis.

　　The schematics are accompanied by a comprehensive suite of measurements, all simulation is fully automatic, no need to set up special simulation settings.
